Sprinter 170 HR Nomad Layout Van DIY Build Kit with Ceiling, Walls, Floor, Bed, Kitchen Galley & Cabinets

Introducing the Nomad Layout for the Sprinter 170, meticulously designed for those who seek to maximize their time on the road without sacrificing comfort or functionality. This layout optimizes space for storage and usability, providing easy access to essential amenities such as sleeping, cooking, and a toilet. With a focus on maximizing storage both above and below the bed, the Nomad Layout ensures that you have everything you need for extended journeys while keeping your living space organized and efficient.

The Nomad Layout features a thoughtfully designed sleeping area that maximizes space, allowing for a comfortable night’s rest after a long day of adventure. The kitchen area is equally impressive, providing ample room for meal preparation and storage of cooking essentials. The accessible garage area is perfect for stowing away gear, making it easy to keep your living space clutter-free. This layout is ideal for those who prioritize convenience and accessibility while on the road. To enhance your van's interior, the Nomad Layout includes a variety of kits, such as the Ceiling Panel Kit, Wall Panel Kit, and Flooring Kit. Each component is designed to work seamlessly together, creating a cohesive and stylish interior.

In this kit you will get the items below! By purchasing the Full Build DIY Kit you will save $2,750!

• Prefinished Maple Ceiling Kit
• Prefinished Maple Wall Panel Kit
• Standard Flooring Kit (lonseal not included)
• 72" 4-Piece Bed System in Stealth + Bamboo
• (2) 40" Storage Benches in Stealth + Bamboo
• Prefinished Maple Tapered Kitchen with Drawer Bank + ISOTHERM DR-130 + Sink preinstalled
• 60" Full Depth Squared Overhead Cabinet in Stealth + Bamboo (Driver)
• (2) 40" Low Pro Squared Overhead Cabinets in Stealth + Bamboo (Pass)
• Perfect Fit Mattress - Squared Solid

The Nomad Layout also includes essential furniture pieces, such as the Wheel Well Box Bed System and Tapered Kitchen Cabinet, which provide both comfort and functionality. The kitchen cabinet is designed to accommodate a sink and fridge, while the overhead cabinetry offers additional storage without compromising headroom. With the Nomad Layout, you can enjoy a well-organized and functional living space that caters to all your needs while on the road.

The Nomad Layout for the Sprinter 170 is the ultimate solution for van lifers and adventure seekers who want to maximize their living space without compromising on comfort or functionality. This comprehensive kit is designed to cater to all your needs while on the road, providing a well-thought-out layout that enhances accessibility to essential amenities. With its combination of ample storage, a fully equipped kitchen, and a comfortable sleeping area, the Nomad Layout allows you to travel with ease and confidence. Investing in this kit means you’re not just purchasing components; you’re creating a versatile and efficient living environment that transforms your van into a true home on wheels, making every journey more enjoyable and stress-free.

Maximized Sleeping Space: Optimized design for a comfortable sleeping area.
Maximized Kitchen Space: Ample room for meal preparation and storage.
Maximized Storage: Efficient use of space above and below the bed for gear and essentials.
Accessible Garage Area: Convenient storage for easy access to your gear.
Comprehensive Kits: Includes ceiling, wall, and flooring kits for a cohesive interior.
Box Bed System: Taller sleeping platform for enhanced garage storage.
Tapered Kitchen Cabinet: Designed for larger appliances with integrated sink and storage.
Overhead Cabinetry: Full depth and low profile options for versatile storage solutions.

This kit is compatible with Sprinter 170 High Roof models. If you have a Sprinter 144 please see our full build options designed for that model.

The Ceiling, Walls and Tapered Kitchen Cabinet in this Nomad Full Build DIY Kit are in Prefinished Maple. The Bed System, Storage Benches and Overhead Cabinets are in Stealth+ Bamboo. Please see the Materials Information Page to learn more about these materials.

• Prefinished Maple Ceiling Kit
• Prefinished Maple Wall Panel Kit
• Standard Flooring Kit (lonseal not included)
• 72" 4-Piece Bed System in Stealth + Bamboo
• (2) 40" Storage Benches in Stealth + Bamboo
• Prefinished Maple Tapered Kitchen with Drawer Bank + ISOTHERM DR-130 + Sink preinstalled
• 60" Full Depth Squared Overhead Cabinet in Stealth + Bamboo (Driver)
• (2) 40" Low Pro Squared Overhead Cabinets in Stealth + Bamboo (Pass)
• Perfect Fit Mattress - Squared Solid
• All Necessary Installation Hardware

Installation Difficulty: Medium | 2 people
Installation Time: 1 - 2 Days | 3 days curing time
Tools Needed: Power Drill, Rivet Nut Tool, Screw Driver, Drill Bits

Can you do window cutouts on this kit?

We can do any Factory Sized Window Cutout.  Just leave a note during checkout!

How do some of the Mercedes Sprinter wall panel kits vary?

The Mercedes Sprinter Van interior designs changed in 2018 with two key features that changed wall paneling. First newer models began featuring factory holes on Upper Wall Panels. While the holes are still pre-drilled on the wall panels, they do not have correlating factory holes and the wall paneling will need to serve as a drilling template for rivet-nut installation. Also newer models have redesigned rear doors that use exterior hinges as opposed to older models that require interior hinges. The wheel well panels in older models have a cutout specifically designed to house the retracting rear door catch. Additionally, lower back door panels have a different shape for older model sprinters.

How does the subfloor get installed?

While the included fasteners are sufficient, the addition of contact cement is recommended.   We use SikaFlex 221 to install our flooring kits without fasteners.

How does the ceiling kit mount?

All Mercedes Benz sprinter kits are designed to fit directly into the factory holes in your ceiling. The factory holes will need to be bored out to 3/8" for rivet nut inserts before installation. All panels are mounted 0.125" apart and cover the entirety of the ceiling between walls.

 Will the ceiling kits work with ceiling fan cutouts?

Yes, our team can pre-cut a fan for you if requested. We will reach out to you once your order has been placed and walk you through measuring your fan cutout.
